| GENSET Model | YKD4500i | ||
| Rated frequency (Hz) | 50 | Engine model | 186FGE (8.5HP) |
| Rated voltage (V) | 230 | Engine type | 1 cylinder, diesel engine |
| Rated current (A) | 19.6 | Displacement (cc) | 418 |
| Rated speed (r/min) | 3300 | Fuel capacity (L) | 16 |
| Rated output (W) | 4500 | Cont. running time (Hrs.) | 8.0 @ rated power |
| Max. output (W) | 5000 | Starting system | Electric starter |
| Phase number | Single | Packing size L×W×H (mm) | 930×620×860 |
| DC output | 12V-5A | Net / Gross weight (kg) | 130 / 150 |
| Noise level (dB/7M) | 66.42 | QTY 20’GP / 40’HQ (Sets) | 40 / 126 |
Dual-alternator 100% copper winding
UltrastrongLoading Capacity 3P AC+2200W Air compress+1000W lamps
Super Silent Design
